Video Cable Percon RG 214
Percon
Video Cable Percon RG 214

Video Cable Percon RG 214

0317

50 Ohm analogue coaxial cable. Typically used for equipment, rack and installation applications.

COLOUR
  • Black
CUBIERTA

Product Details

Nº conductors
1
Conductor
CuAg
AWG
12
Stranding
7/21
Section (mm2)
2.70
Insulation
PE
Shield
CuAg+CuAg
Nominal Size
10.7
Weight (Kg)
208
Colour
Black
Use
fixed installation
Jacket
FRLSZH
0317

Description

50 Ω RF coaxial cable with silver-plated copper conductor and double shield, and FRLSZH jacket, for equipment, racks and fixed installation.

The Percon RG 214 is a 50 Ω analogue radio frequency coaxial cable designed for the most common RF applications: equipment interconnection, rack wiring and fixed installations.

Its 7-strand 2.70 mm² (12 AWG) silver-plated copper (CuAg) conductor with PE insulation ensures efficient signal transmission. The double silver-plated copper shield provides high protection against interference, essential in RF applications.

With a nominal outer diameter of 10.7 mm, a weight of 208 kg/km and a black FRLSZH jacket — flame retardant, low smoke and zero halogen — it is a robust, safe choice for permanent installations.

Key features

  • 50 Ω radio frequency coaxial
  • 7-strand silver-plated copper (CuAg) conductor, 2.70 mm² (12 AWG)
  • PE insulation
  • Double silver-plated copper shield
  • Designed for fixed installation
  • Black FRLSZH jacket (flame retardant, low smoke, zero halogen)
  • Nominal outer diameter: 10.7 mm · Weight: 208 kg/km
