HDMI to HDMI with audio extraction,UHD-4K 1.4 MUXLAB/500431

The HDMI to HDMI switch with audio extraction allows you to distribute one (1) HDMI source to one (1) HDMI display. The switch supports up to 4K (3840 x 2160), 8-bit color, and HD audio. Audio extraction is available via an S/PDIF Toslink connector and a 3.5 mm stereo jack. The product is HDCP 1.3 compliant and features LED diagnostics.

UPC: 627699004319

Also known as: 5M-500431

Technical Specifications:

Warranty: 2 years

Compliance: Standards: FCC, CE, RoHS

Power Supply: 5V DC, 2A with interchangeable blade for US, UK, and European markets.

Weight: 1 lb (0.45 kg)

Dimensions: 95 mm x 83 mm x 23 mm

Casing: Metal case

Temperature: Operating: 0° to 40°C, Storage: -20° to 60°C, Humidity: Up to 90% non-condensing

Cable: HDMI cable

HDCP: Revision 1.3

Sampling Rate: HDMI Output: 192 kHz, Optical Output: 192 kHz, Stereo Output: 48 kHz

Audio Format: HDMI Output: LPCM, Dolby Digital, DTS, Dolby Digital Plus, Dolby, True-HD, DTS-HD Master Audio, Optical Output: LPCM, Dolby Digital, DTS, Stereo Output: Analog stereo

Color: 8, 10, and 12-bit

Resolution: 480i to 1080p at 50/60 fps, 1080p at 24/50/60 fps 3840 x 2160 at 24/25/30 fps, VGA to UXGA

Power Control: Press the button on the front of the unit

LEDs: One (1) Power: Blue, One (1) LPCM: Blue, One (1) Sync: Blue

Connectors: 19-pin HDMI Type A female, Toslink, and 3.5 mm stereo jack

Signals: HDMI 1.4 protocol

Frequency: 25 to 340 MHz

Transmission: Transparent to the user

Devices: DVD/Blu-ray, plasma, projectors, monitors, TVs, PCs, laptops

Environment: HDMI 1.4 (3D)
