TVL range digital multicore cable combining 2 digital video coaxials and 2 × 2.5 mm² power conductors in a single run. Ideal for mobile applications.
The Percon TVL 2020 is a TVL range digital multicore cable designed for the combined distribution of video and power in a single run, simplifying cabling and speeding up set-up in mobile applications.
It includes two digital video coaxials (VK 7 type), each with a 0.785 mm² (18 AWG) solid copper (EHC Cu) conductor, foamed high-density polyethylene (FHDPE+) insulation and a double tinned copper shield; and two stranded 2.5 mm² (14 AWG) tinned copper (CuSn) power conductors with PTC insulation.
With a nominal outer diameter of 17 mm and a weight of 409 kg/km, it is available with a black PTC or NBR jacket, making it a robust solution for OB vans, cameras, events and live productions.
Key features
- TVL digital multicore: 2 digital video coaxials + 2 power conductors
- Coaxials (VK 7 type): solid EHC Cu, 0.785 mm² (18 AWG), FHDPE+ insulation, double tinned copper shield
- Power: stranded CuSn, 2.5 mm² (14 AWG), PTC insulation
- Designed for mobile use
- Black PTC or NBR jacket
- Nominal outer diameter: 17 mm · Weight: 409 kg/km
